???? E2V MG5436 Magnetron

Description:?The E2V MG5436 is a compact, rugged, and lightweight fixed-frequency pulse magnetron specifically designed for marine radar applications. Built with E2V technology, it ensures reliable performance in challenging maritime environments with stable RF output and long service life. This X-band magnetron is trusted for critical radar operations in marine navigation and safety systems.

Specifications:

• Model: MG5436

• Frequency Range: 9410 ± 30 MHz

• Output Power: 25 kW (Peak)

• Heater Voltage: 6.3 V

• Heater Current: 0.5 A

• Cathode Pre-heating Time: 60 seconds minimum

• Cooling: Natural Air Cooling

• Weight: 0.7 kg (approx.)

• Coupler: IEC UBR100

• Applications: Marine Radar Systems, Navigation Equipment

• Manufacturer: E2V Technologies (UK)

• Compliance: CE Certified, ISO Standards
